GPX-A-SERIES
GPX-A - Multi-Power & CCT Garden/Side Walk Post Lights
Technical Specs
- :: Voltage: 100-277V AC 50/60Hz
- :: Wattage: 18W-150W
- :: Power Factor: 0.95
- :: Efficacy: 137-150LM/W
- :: Aluminum Housing, Outdoor Powder Coated
- :: Programmable Bi-Level Motion Sensor & Emergency Backup Options
- :: Operating Temperature: -86°F~122°F
- :: IP Rating: IP66, Suitable for Wet Locations
- :: 7-Year Warranty
- :: Multi CCT and Power: Selectable Switch Inside of the Fixture
- :: Dimmable: 0~10V Dimming
- :: LED: SMD 3030
- :: Total Lumens: 9000LM-22500LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: Color Rendering index: >70
- :: Beam Angle: Type V (150° X 150°)
- :: Lifespan: 70000 Hrs.
Applications
- :: Ideal for gardens, amusement parks, residential quarters, industrial parks, and pedestrian streets.
- Variations
- Q & A
| Product Name | Lumens | Watts | Description | Voltage | Factory-Install Options | Features | |
|---|---|---|---|---|---|---|---|
GPX-18-60W-MCTP-A1  SPEC  IES MANU | 9000LM Max. | 18W/30W/45W/60W | Single Arm Mount | 100-277V AC 50/60Hz |
|       | |
GPX-18-60W-MCTP-A2 SPEC MANU IES | 9000LM Max. | 18W/30W/45W/60W | Twin Arm Mount | 100-277V AC 50/60Hz |
| | |
GPX-22-75W-MCTP-A1 SPEC IES MANU | 11250LM Max. | 22W/37W/56W/75W | Single Arm Mount | 100-277V AC 50/60Hz |
| | |
GPX-22-75W-MCTP-A2 SPEC MANU IES | 11250LM Max. | 22W/37W/56W/75W | Twin Arm Mount | 100-277V AC 50/60Hz |
| | |
GPX-90-150W-MCTP-A2 SPEC MANU IES | 22500LM Max. | 90W/120W/150W | Twin Arm Mount | 100-277V AC 50/60Hz |
| |
