CL-FLTW-75-110W-50K-E39
LED 180 Degree Flat HID Retrofit Lamps, 75W/97W/110W, 5000K
Technical Specs
- :: Voltage: 120-277V AC 50/60Hz
- :: Wattage: 75W/97W/110W
- :: AC Direct / Bypass Existing Ballast
- :: Power Factor: >0.9
- :: THD: ≤20%
- :: Efficacy: 150LPW
- :: Housing: PC + Aluminum, Pure aluminum heatsink, NO Fan
- :: E39 Mogul Base
- :: Adjustable lenses (0° - 75°)
- :: Meet 6KV Surge Immunity Level
- :: Suitable for use in enclosed luminaires, min.
- :: lamp compartment dimensions: 17.32” X 10.23 X 10.23”
- :: Direct Replacement for Metal Halide, Easy Installation
- :: Operating Temp: -40°F to 122°F
- :: IP 64 Suitable for Damp Location
- :: Multi Power (Selectable Switches On the Bottom of The Lamp)
- :: LED SMD type: SMD 2835
- :: Total Lumens: 16500LM Max.
- :: Color Temperatures: 5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 120°
Applications
- :: Replacement Lamps for Outdoor Pole/Arm-mounted Area and Roadway Luminaires(UL Type B).
