SPEC SHEET

DMX-WW-36W-RGBW-BT-BK

DMX 512 Compatible RGBW Square Flood Light, 36W

Technical Specs

  • :: Voltage: 120-277V
  • :: Power Factor: >0.9
  • :: Wattage: 36W
  • :: Efficacy: 44 LPW
  • :: Operating Voltage: Max 900 mA, Max 36VDC
  • :: DMX 512 Compatible. DMX Controller & Cables Needed
  • :: In A DMX Lighting Setup, Lights Need To Be Connected With cables. The Cables Can Be “Daisy Chained” So That Each Light Can Plug Into The One Before It Instead Of All Lights Plugging Into The DMX Board Itself
  • :: Die-cast Aluminum Housing with Powder Coat Finish Solid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
  • :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
  • :: 90° Adjustable Surface Mount Bracket
  • :: High Conductive Aluminum LED Board
  • :: Operating Temperature: -40°F to 104°F
  • :: IP Rating: IP65, Suitable for Wet Locations
  • :: 7-Year Warranty Color Temperatures: RGBW Selectable Through DMX Controller
  • :: Dimming: Dimmable Through Phone App
  • :: Total Lumens: 710LM(Warm White) 1600LM (Cool White)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Beam Angle: 60°

Applications

  • :: The fixture has classic traditional appearance, professional light distribution design, 90-degree beam angle, ideal for park landscaping, garden, architectural landscape lighting, suitable for wet locations

Features

  • UL Listed
  • Wet Location
  • IP65
  • Dimming 0-10V
  • 7 year warranty

ACCESSORIES

Product NameDescription
Half Glare Shield for TC-LIN-36W/72W & DMX-LIN-36W
