IGLA-3W-30K-BN

:: Voltage: 12-24V AC/DC
:: Power Factor: >0.9
:: Wattage: 3W
:: Input current: 1A Max
:: Efficacy: 106LPW Die-cast Aluminum Housing Traffic Rated: They are not likely to get damaged from activity around the light, including lawn care, as well as foot and auto traffic
:: Optical PC Flat Lens
:: 4” PVC Sleeve with three 1/2” KO. 2 on sides, 1 on bottom
:: Solid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
:: High Conductive Aluminum LED Board
:: IP Rating: IP67
:: Operating Temperature: -4°F to 104°F
:: Suitable for Wet Locations
:: 1-Year Warranty
:: LED: Built in integrated LED
:: Total lumens: 320LM
:: Color Temperatures: 3000K
:: Color Rendering Index: CRI ≥ 90
:: Beam Angle: 30°
:: Lifespan: 50,000 Hrs.

:: The fixture has classic traditional appearance, professional light distribution design, ideal for park landscaping, garden, architectural landscape lighting, suitable for wet locations
