LFX-SM-10-30W-30K-TR

LFX LED Small Multi-Power High Lumen Flood Light with U Bracket

Technical Specs

  • :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze & White Finish)
  • :: DLC Premium & LED High-Lumen Flood Lights
  • :: Solid State Lighting Technology for Long Life; No Maintenance Needed
  • :: 270° Adjustable Yoke Mount
  • :: Lens: Optical Type III
  • :: Lumens: 1300LM-4080LM
  • :: Wattage: 10-30W
  • :: Voltage: 120-277V AC 50-60Hz
  • :: LED: Lumileds Luxeon 2835 High Flux LED
  • :: Efficacy: 130LPW
  • :: Power Factor: >0.9
  • :: Operating Temp: -40°F to 104°F
  • :: Beam Angle: 90° x 120°
  • :: Color Rendering Index: CRI ≥ 82
  • :: 7-year warranty
  • :: IP Rating: IP65, Wet Location

Applications

  • :: Ideal for general site lighting, alleys, loading docks, doorways, pathways and parking areas.

Features

  • UL Listed
  • DLC Listed
  • Wet Location
  • IP65
  • Dimming 0-10V
  • 7 year warranty
