SCX4-2FT-20W-MCT4-D
LED 4" Superior Architectural Seamless Linear Lights, 20W, 3000K/3500K/4000K/5000K
Technical Specs
- :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 20W
- :: Power Factor: >0.95
- :: LPW: 104/106/107/117
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Make Different Connections via T/L/X Joints on Both Ends
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 2314M/ 2511LM/ 2418LM/ 2438LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable with Switch Inside the Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
Applications
- :: Ideal for offices, hotels, corridors, saloons, libraries, meeting rooms, conference halls, and the best solution for modern lighting solutions
- :: It can be used in any indoor applications
Features
ACCESSORIES
| Product Name | Lumens | Color Temp | Dimensions | Description | |||
|---|---|---|---|---|---|---|---|
 SCX4-L-MCT4  SPEC  IES LUX | 508LM/575LM/616LM/660LM | 3000K/3500K/4000K/5000K | 3.35” X 6.61”X 6.61” | Joint Type: L | |||
 SCX4-T-MCT4 SPEC IES LUX | 629LM/726LM/787LM/854LM | 3000K/3500K/4000K/5000K | 3.35” X 6.61”X 6.61” | Joint Type: T | |||
 SCX4-X-30K SPEC IES LUX | 733LM/863LM/944LM/1037LM | 3000K/3500K/4000K/5000K | 3.35” X 3.35” | Joint Type: X | |||
 SCX4-IC-MCT4 SPEC IES LUX | 629LM/726LM/787LM/854LM | 3000K/3500K/4000K/5000K | 3.35” X 4” X 6.97” X 6.97” | Joint Type: Inside Corner |
OPTIONS
