WLL-157-30K-BK
Integrated LED Well Lights, 6W, 3000K
Technical Specs
- :: Voltage: 12-24V AC/DC
- :: Power Factor: >0.9
- :: Wattage: 6W
- :: Input Current: 1A Max
- :: Efficacy: 83LPW
- :: Die-cast Aluminum Housing
- :: PC Halfmoon Frosted Lens Suitable for Path Lighting
- :: 3" PVC Sleeve with three 1/2" KO. 2 on sides, 1 on bottom
- :: Solid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: PC Halfmoon Frosted Lens Suitable for Path Lighting
- :: 3" PVC Sleeve with three 1/2" KO. 2 on sides, 1 on bottom
- :: Solid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: IP Rating: IP65
- :: Operating Temperature: -4°F to 104°F
- :: Suitable for Wet Locations
- :: 1-Year Warranty
- :: LED: Built in integrated LED
- :: Total Lumens: 500LM
- :: Color Temperatures: 3000K
- :: Color Rendering Index: CRI ≥ 90
- :: Beam Angle: 52°
- :: Lifespan: 50,000 Hrs
Applications
- :: The fixture has classic traditional appearance, professional light distribution design, ideal for park landscaping, garden, architectural landscape lighting, suitable for wet locations
